6

Preparing for use

134

5,27 in.

When the hose is not fitted, the hole can

be closed with the flange cap .

NOTE: When installing the air conditioner

semi-permanently, you should leave a door

slightly open (as little as 1 cm) to guarantee

correct ventilation.

11

12

in the window

pane

in the wall: you are

recommended to

insulate the section

of wall using suit-

able insulation.

in the wooden

kickboard of a

French window

I

French window

• Attach the window outlet

to the air

exhaust hose as shown in fig. F.

20

G

• Open the French window slightly and posi-

tion the outlet as shown in figure G

20

2

1

Keep the air hoses as short and free of

curves as possible to avoid constrictions.

F

SEMI-PERMANENT INSTALLATION

If required, your appliance can also be

installed semi-permanently (Fig. H).

30 cm

30 cm

Proceed as follows:

• Drill a hole (ø134mm / 5,27 in.) in an out-

side wall or through a window pane.

Respect the height and dimensions of the

hole given in figures M and I.

H

• Fit the wall flange into the hole.

• Screw the hose to the adaptor ,

that was already fitted to the appliance (fig.

A).

• Remove the

plastic end

of the hose

by

unscrewing it

and in its

place screw

the wall

mounting

accessory

(fig. L).

• Fit the end of the hose to the wall

flange as shown in fig. M.

14

12

1312

11

11

12

1

2

L

M

MAX100 cm

MAX 39,37 inches

MIN 35 cm

MAX 13,77 inches
